Xylene Detector Product Model: DP-C8H10
The DP-C8H10 Xylene Detector is a safe and reliable device designed for continuous monitoring of volatile xylene gas concentrations. It uses high-quality sensors and microcontroller technology from renowned global manufacturers, ensuring fast response, high accuracy, and excellent stability. This makes it one of the top-performing gas detection systems in the domestic market. Users can customize parameters according to their needs, and the operation is straightforward and user-friendly. The instrument is equipped with a large-capacity nickel-metal hydride rechargeable battery, providing long standby time. Its compact design is both durable and aesthetically pleasing, featuring a digital LCD backlight display that is clear and easy to read. It also includes a two-level sound and light alarm system, allowing for timely and accurate alerts when preset concentration thresholds are reached. The housing is made from high-strength ABS engineering plastic, offering a stylish and robust appearance that feels comfortable to hold and lasts for years. In terms of technology, the DP-C8H10 can use either an infrared sensor or a PID (Photoionization) sensor. The PID sensor works by exposing the target gas to ultraviolet light, causing ionization. These ions then generate a current between electrodes, which is amplified and used to detect gas levels. This method offers high sensitivity, no risk of poisoning, and ensures safety and reliability over its long service life of up to 7 years.
Technical Specifications:
Detection Gas:
Toluene (PID or Infrared Sensor, 7-Year Service Life)
Range:
0-10ppm, 50ppm, 1000ppm, 2000ppm, 6000ppm, 10000ppm (Optional)
Resolution:
0.01 ppm (0–50 ppm); 0.1 ppm (0–1000 ppm); 1 ppm (Above 1000 ppm)
Detection Accuracy:
≤±1% (Actual Concentration, Higher Accuracy Based on Specific Sensor)
Repeatability:
≤±1%
Response Time:
≤10 seconds (T90)
Linearity Error:
≤±1%
Recovery Time:
≤10 seconds
Detection Principle:
PID or Infrared
Zero Drift:
≤±1% (FS/year)
Display Method:
LCD Backlit Display
Alarm Method:
Dual-Level Sound and Light Alarm, ≤80 dB
Detection Method:
Pumping Type, Automatic Pumping for Real-Time Detection, More Accurate and Faster Results
Data Recovery:
One-Click Restore to Factory Settings, Easy and Fast, No Need to Worry About Misuse
Automatic Diagnosis:
System Check: Battery Level, Display, Sensor, Hardware Faults
Protection Rating:
IP65
Operating Temperature:
-30°C to +70°C
Explosion-Proof Grade:
Exia II CT6 (Intrinsically Safe)
Operating Humidity:
≤95% RH (No Condensation)
Dimensions:
134 × 61 × 32 mm (L × W × H)
Working Pressure:
≤100 kPa
Weight:
300g
Power Supply:
2800mA Rechargeable Lithium Battery
Accessories:
Packing Box, Manual, Charger, Special Leather Case (Optional)
